Era Multipoint Lock - 2 Rollers, 1 Latch, 1 Deadbolt.

Suitable for a uPVC Door. Sprung mechanism - accepts unsprung handles.

Can be used as Lever/Lever operation (solid spindle) or Lever/Pad operation (split spindle). Optional shoot bolt engagement for additional security.

Designed to meet the requirements of PAS 23 and PAS 24. Licensed by Secured by Design. Shorter version available HERE.

Technical Information: Centre of spindle to centre of top roller: 815mm Centre of spindle to centre of top hook: 725mm Centre of spindle to centre of bottom hook: 750mm Centre of spindle to centre of bottom roller: 830mm

Available with: 35mm Backset (112632)

L/L: Lever Operated.

To Lock - Lift handle up to engage locking points. One Full turn of the key & the door is now locked.

To Open From Inside - Turn key and push down on the handle.

To Open From Outside - Turn the key, push down on the handle and then turn key to release the door latch.
